Using the Configuration Menus
32
The following tables list the input card types and their relevant parameters.
HDMI plus Analog Audio Input Card
Parameter Description Options
36.Reset SubBoard Re-power: power cycles the port
Factory: performs a factory reset to default values of the port
Re-power
81.Volume 0 to 100: sets the audio input volume 50
84.Audio Balance 0 to 100: sets the audio input channel balance 50
87.Audio Bass 0 to 100: sets the audio inout bass level 50
88.Audio Treble 0 to 100: sets the audio input treble level 50
91.Audio Mute MUTE: mutes the audio input
Non-MUTE: unmutes the audio input
Non-MUTE
98.Audio Select Auto: audio signal selection is controlled by the presence or absence
of a plug in the 3.5mm mini jack
AUD-Embedded: HDMI audio is selected
AUD-Ex-Digital: S/PDIF audio is selected (only works on HDMI plus
S/PDIF card)
AUD-Ex-Analog: Analog audio from the 3.5mm mini jack is selected
(only works on HDMI plus analog audio card)
Auto
HDMI plus S/PDIF Audio Input Card
Parameter Description Default
36.Reset SubBoard Re-power: power cycles the port
Factory: performs a factory reset to default values of the port
Re-power
98.Audio Select Auto: audio signal selection is controlled by the presence or absence of
a plug in the 3.5mm mini jack
AUD-Embedded: HDMI audio is selected
AUD-Ex-Digital: S/PDIF audio is selected (only works on HDMI plus
S/PDIF card)
AUD-Ex-Analog: Analog audio from the 3.5mm mini jack is selected
(only works on HDMI plus analog audio card)
Auto
HDBaseT Input Card
Parameter Description Options
36.Reset SubBoard Re-power: power cycle the port
Factory: perform a factory reset to default values of the port
Re-power
98.Audio Select Auto: audio signal selection is controlled by the presence or absence of
a plug in the 3.5mm mini jack
AUD-Embedded: HDMI audio is selected
AUD-Ex-Digital: S/PDIF audio is selected (only works on HDMI plus
S/PDIF card)
AUD-Ex-Analog: Analog audio from the 3.5mm mini jack is selected
(only works on HDMI plus analog audio card)
Auto
