Using the Configuration Menus
29
29
The TAKE button flashes.
4. Press TAKE.
The setup is stored in the selected preset for subsequent recall.
The display reverts to the output/input display.
8.1.6 Setup Menu—6: recall setup XX, Recalling a Preset
This option recalls a stored configuration from a preset (1 to 59).
To recall a stored configuration:
1. Press MENU.
The Setup Menu options are displayed.
2. Press 6 (RCL) on the numeric keypad (see Figure 2 ).
The following is displayed:
recall <= __
3. Using the numeric keys, enter the preset (in this example, 02) to recall.
The following is displayed:
Wait …..
After a few seconds, the following is displayed on the right hand side:
CONFIRM
RECALL <= 02
The TAKE button flashes.
4. Press TAKE.
The preset is recalled.
The display reverts to the output/input display.
8.2 Using the Config Menu
The Config Menu provides access to configuration settings that are not regularly
changed and comprises the following options:
• Input signal detection ( Section 8.2.1
• Input port parameter setting (
)
Section 8.2.4
• Output load detection (see
)
Section 8.2.3
• Output port parameter setting (
)
Section 8.2.4
• Interface configuration (see
)
Section 8.2.5
• Interface reply configuration (
)
Section 8.2.6
• Protocol switching (
)
Section 8.2.7
• Storing the default setup (
)
Section 8.2.8
• Resetting the VS-1616D (
)
Section 8.2.9
• Firmware revision display (
)
Section 8.2.10 )
