8.1.3 Setup Menu—7: EDID, Assignment to an Input
This option assigns an EDID to between one and eight inputs in non-volatile
storage. More than eight EDID assignments must be assigned in multiple batches.
Each input on the VS-1616D has a factory default EDID loaded (see
Section 15 ).
The EDID for each input can be changed independently via the menu (described
below) or by uploading an EDID binary file to each input via the RS-232 port
using Kramer K-Sara software 1
Note: It is necessary to have a display/device connected to the output from which
you want to read the EDID. Failure to do so results in the default EDID being
written to storage.
.
To assign an EDID to between one and eight inputs:
1. Press MENU.
The Setup Menu options are displayed.
2. Press 7 (EDID) on the numeric keypad (see Figure 2 ).
The following is displayed:
SETUP EDID
ENTER to View EDID and Set EDID
3. Press ENT.
The current EDID matrix configuration is displayed.
4. Using the numeric keys, enter the input in which to store the EDID (in this
example, 08), and enter the output (in this example, 05) from which to read
the EDID.
The following is displayed:
01 02 03 04 05 06 07 08
05 out05 => in08
The TAKE button flashes.
5. Repeat Step 4 for up to eight inputs.
6. Press TAKE.
The EDID is stored and passed through to the input.
The display reverts to the output/input display.
To view the EDID assignments:
1. Press MENU.
The Setup Menu options are displayed.
2. Press 7 (EDID) on the numeric keypad (see Figure 2 ).
The following is displayed:
SETUP EDID
ENTER to View EDID and Set EDID
