Using the Configuration Menus
33
33
VGA Input Card
Parameter Description Default
1.DE (Auto, Manual, Do-Auto) Auto
2.Phase (Manual, Do-Auto) Manual
20.Brightness (0–63) 32
21.Contrast (0–63) 32
22.Hue (0–63) 0
23.Saturation (0–63) 0
30.Phase adjustment (0–255) 0
36. Reset SubBoard Re-power: power cycle the port
Factory: perform a factory reset to default values of the port
Re-power
42.Video Format (VGA, RGBHV, RGsB, RGBS, YUV) VGA
64.Hor-Total Pixels 1688
67.Horizontal-DE-Start 358
68.Horizontal-DE 1279
69.Vertical-DE-Start 41
70.Vertical-DE 1023
73.SETUP (0–127) 0
74.RECALL (0–121) 0
8.2.3 Config Menu—Output Load Detection Display
This option displays a list of outputs and indicates which have loads attached to
them.
To display a list of outputs and attached loads:
1. Press MENU twice.
The following message is displayed:
start configuration menu
MENU to view setup ENT to change them
2. Press MENU until the following is displayed:
OUT: 01 02 03 04 05 06 07 08 09 10 11
LOAD: Y X Y Y Y Y X Y Y Y X
Y indicates that a load is attached and X indicates that no load is detected on
the relevant output.
3. Do one of the following:
 Press BREAKAWAY to exit the Config Menu
 Wait approximately 15 seconds for the operation to time out
 Press MENU to move to the next Config Menu option
