Technical Specifications
46
Table 10: Technical Specifications of VS-1616D Compatible Cards
MAX RESOLUTION: Up to UXGA; 1080p, 1920x1200
Card
Po
rt
s
B
an
dw
id
th
pe
r C
ha
nn
el
C
om
pl
ia
nc
e
HDM
I
Su
pp
or
t
3D
P
ass
Th
ro
ug
h
Fe
at
ur
es
HDT
V
C
om
pa
tib
le
DVI 2 DVI-D on DVI-I
connector
1.65Gbps DVI 1.0
Kramer
Equalization &
re-Klocking™
Technology
Yes
DVI Dual
Channel
2 DVI-D on DVI-I
connector
3.3Gbps DVI 1.0
HDCP 2 HDCP 2.25Gbps
HDCP/HDMI
V.1.4 with
Deep
Color,
x.v.Color™
Yes
HDMI 2 HDMI 2.25Gbps
HDMI plus
Digital
Audio
2 HDMI
2 Digital audio on an
RCA connector
2.25Gbps
HDMI plus
Analog
Audio
2 HDMI
2 Analog audio on
3.5mm mini jacks
2.25Gbps
DVI (4LC
Fiber
Optic 1
2 4 LC
)
1.65Gbps DVI 1.0
DVI
(SC Fiber
Optic 2
2 SC
)
2.25Gbps DVI 1.0
DGKat 3 2 TP DGKat ports on
RJ-45
2 Serial ports on 3-pin
terminal blocks
plus
RS-232
Video:
1.65Gbps
Serial Data:
19200
DVI 1.0
HDBaseT 3 2 HDBaseT TP on RJ45
connectors
2 RS-232 Serial ports
and 2 IR ports on a
10-pin terminal block
1 Ethernet port on an
RJ-45 connector
Video:
6.75Gbps
(2.25Gpbs
per graphic
channel)
Serial Data:
19200
DVI 1.0
VGA 2 VGA on 15-pin HD
connectors
1 Multi-mode glass fiber cables with LC connections must be used, such as the Kramer C-4LC/4LC
2 Multi-mode glass fiber cables with SC connections must be used, such as the Kramer C-SC/SC/OM3
3 Twisted pair cables with RJ-45 connections must be used, such as the Kramer BC-DGKat623
