Configuring the Number of Installed Input and Output Ports
39
39
8.2.10 Config Menu—Display Firmware Versions
This option displays the main and front firmware versions.
To display the firmware versions:
1. Press MENU twice.
The following message is displayed:
start configuration menu
MENU to view setup ENT to change them
2. Press MENU until the following is displayed:
Main Firmware Version: 1.0
Front Firmware Version: 1.0
3. Either:
 Press BREAKAWAY to exit the Config Menu
 Wait approximately 15 seconds for the operation to time out
9 Configuring the Number of Installed Input and Output Ports
After installing or removing a module you need to set the number of input and
output ports so that the VS-1616D recognizes the new configuration. Refer to
Section 6.1
To set the number of input or output ports:
for an explanation of port numbering before setting the number of input
and output ports.
1. Press ESC, ENT and LOCK together.
The following is displayed:
Configuration Device
2. Press ENT.
The following is displayed:
Test Board: 0 MaxInput:16 MaxOutput:16
Note: The number of input and output ports can only be set in units of two, for
example, 4 x 4, 16 x 4 or 12 x 16.
3. Using the numeric keys, enter the number of input and output ports installed.
The TAKE button flashes.
4. Press TAKE.
The number of installed ports is saved and the display reverts to the
output/input display.
5. Reboot the device by turning the power off and then on again.
