Using the Configuration Menus
30
To enter the Config Menu press MENU twice. The MENU button lights and the
following message is displayed:
Start configuration menu
MENU to view setups ENT to change them
When browsing through the configuration menu, enabled buttons light or flash.
Use the Config Menu as follows:
1. Press the MENU button to cycle through the menu items 1
2. Press the ENT button to enter a submenu.
.
3. After entering a submenu, you can select between several options.
Select an option by pressing one of the illuminated buttons in the Selector
Buttons area.
4. After selecting the desired option, a description of the desired change is
displayed and the TAKE button flashes.
5. Press the flashing TAKE button to confirm the change.
A description of the current state is displayed for about one second. The unit
automatically switches to the next item in the menu.
8.2.1 Config Menu—Input Signal Detection Display
This option displays a list of inputs and indicates on which of them signals have
been detected.
To display a list of inputs that have detected signals:
1. Press MENU twice.
The following message is displayed:
start configuration menu
MENU to view setup ENT to change them
2. Press MENU.
The following is displayed:
IN: 01 02 03 04 05 06 07 08 09 10 11
OUT: Y X Y Y Y Y X Y Y Y X
Y indicates that a signal is detected and X indicates that no signal is detected on
the relevant input.
3. Do one of the following:
 Press BREAKAWAY to exit the Config Menu
 Wait approximately 15 seconds for the operation to time out
 Press MENU to move to the next Config Menu option
1 The LCD display shows the current status of the selected menu item
