Installing and Using the Test Module to Troubleshoot Video Problems
40
10 Installing and Using the Test Module to Troubleshoot Video
Problems
The VS-1616D includes a test module which can act as a video signal generator
and can be used to diagnose video issues in an operating environment.
The test module must be installed in the configuration before it can be used. When
installing the test module, the number of configured inputs and outputs must be
increased by one. For example:
• If your VS-1616D has four inputs and eight outputs, you must configure the
VS-1616D as 5 x 9
• If your VS-1616D has 16 inputs and 16 outputs, you must configure the
VS-1616D as 17 x 17
10.1 Installing the Test Module
To install the test module in the configuration:
1. Press ESC, ENT and LOCK together.
The following is displayed:
Configuration Device
2. Press ENT.
The following is displayed:
Test Board: 0 MaxInput:16 MaxOutput:16
where 0 indicates that the test module is not installed.
3. Using the numeric keys, press 1 to indicate that the test module is installed.
The TAKE button flashes.
4. Press TAKE.
5. Increase the number of configured inputs and outputs by one (see Section 9
6. Power cycle the device.
The test module is now installed and may be used.
).
10.2 Setting the Resolution of the Generated Video
The test module generates a range of both PC and HD resolutions which are
selected by a combination of DIP-switches and an on-board jumper (labeled B3).
Install the jumper to select HD resolutions or remove the jumper to select PC
resolutions.
The Resolution DIP-switch is used to set the resolution of the generated video as
listed in Table 7 , Table 8 and Figure 13 .
