Technical Specifications
45
45
13 Technical Specifications
lists the technical specifications of the VS-1616D.
Table 9: Technical Specifications of the 16x16 Digital Matrix Switcher
BANDWIDTH:
Supports up to 3.2Gbps bandwidth per channel (limited by the card installed)
MAX RESOLUTION:
Up to UXGA; 1080p, 1920x1200
CONTROLS:
Front panel buttons, Infrared remote control transmitter, RS-232, Ethernet
SWITCHING:
Confirm or At Once for immediate switching
OPERATING
TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE
TEMPERATURE:
–40° to +70°C (–40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
19” x 14.2” x 4U (W, D, H) rack-mountable
POWER
CONSUMPTION:
100-240V AC, 50/60Hz, 135VA
WEIGHT:
8.1kg (17.9lbs) approx
ACCESSORIES:
Power cord, Infrared remote control transmitter
lists the technical specifications of the cards that are compatible with the
VS-1616D chassis.
