Operating Your Video Matrix Switcher
21
21
• Pressing an OUT-IN combination implements the switch without further
user confirmation
• You save time as execution is immediate and actions require no user confirmation
• No protection is offered to correct an erroneous action
In the Confirm mode:
• The TAKE button lights
• You enter an action and then confirm it by pressing the TAKE button
• Every action requires user confirmation, protecting against erroneous actions
• Execution is postponed until you confirm the action 1
7.3.1 Toggling between the At Once and Confirm Modes
To toggle between the At Once and Confirm modes:
Note: If the TAKE button is flashing you cannot toggle between the At Once and
Confirm modes. A flashing TAKE button indicates that an action is currently
pending confirmation.
1. Press TAKE to toggle between the At Once mode and the Confirm mode.
The TAKE button lights and actions now require user confirmation.
2. Press the lit TAKE button to toggle from the Confirm mode back to the At
Once mode.
The TAKE button is no longer lit and actions no longer require user
confirmation.
7.3.2 Confirming a Switching Action
Actions only require confirmation when the device is in the Confirm mode.
To confirm a switching action:
1. Using the numeric keypad, enter an output-input combination.
The TAKE button flashes.
2. Press the flashing TAKE button to confirm the action.
The action is confirmed and the TAKE button lights.
7.4 Switching Actions
This section describes how to:
• Switch one input to one output (see Section 7.4.1
• Switch several inputs to several outputs (see
)
Section 7.4.2
• Turn off several outputs (see
)
Section 7.4.3 )
1 Failure to press the TAKE button within a few seconds results in the action timing out automatically
