Using the Configuration Menus
31
31
8.2.2 Config Menu—Input Port Parameter Setting
This option sets input port specific parameters. Ports that show an X have no
parameters available to modify. Ports that show a 0 have parameters available to
modify. The parameters that are available, such as, audio balance, depend on the
type of card installed and whether the card is an input or an output card. Tables
listing input cards and their parameters can be found at the end of this section.
To set parameters for a port:
1. Press MENU twice.
The following message is displayed:
start configuration menu
MENU to view setup ENT to change them
2. Press MENU until a display similar to the following is shown:
IN: 01 02 03 04 05 06 07 08 09 10 11
SET: X X X X Y Y X Y X X X
X indicates that there are no modifiable parameters for the associated port
and 0 indicates that there are modifiable parameters for the associated port.
3. Press TAKE to enter the list of ports.
The cursor flashes on a selected port.
4. Select the required port using the left and right arrow buttons.
5. Press TAKE to enter the parameters list.
A message similar to the following is displayed with the relevant port number
in place of 06:
IN: 06
SET: 36.Reset SubBoard
6. To select the next parameter press the right arrow button. (See the table at the
end of this section for available parameters.)
Or:
7. To enter the displayed parameter press TAKE.
The parameter options are displayed.
8. Select the required action or number using the keypad numbers and arrows.
9. Press TAKE to save the change.
10. Repeat from Step 6 to modify other parameters
11. Do one of the following:
 Press BREAKAWAY to exit the Config Menu
 Wait approximately 15 seconds for the operation to time out
 Press MENU to exit to the parameter list
