KRAMER: SIMPLE CREATIVE TECHNOLOGY
Connecting the VS-1616D 16x16 Digital Matrix Switcher
16
To connect to the VS-1616D via RS-232:
•
Connect the RS-232 9-pin D-sub rear panel port on the VS-1616D unit via a
9-wire straight cable (only pin 2 to pin 2, pin 3 to pin 3, and pin 5 to pin 5
need to be connected) to the RS-232 9-pin D-sub port on your PC
6.5 Connecting to the VS-1616D via Ethernet
You can connect the VS-1616D via Ethernet using a crossover cable (see
Section 6.5.1
) for direct connection to the PC, or a straight through cable (see
) for connection via a network hub or network router
6.5.1 Connecting the Ethernet Port directly to a PC
You can connect the Ethernet port on the VS-1616D to the Ethernet port on your
PC via a crossover cable with RJ-45 connectors.
This type of connection is recommended for identification of the
factory-default IP Address of the
VS-1616D during the initial configuration
To configure your PC after connecting the Ethernet port:
1. Right-click the My Network Places icon on your desktop.
2. Select Properties.
3. Right-click Local Area Connection Properties.
4. Select Properties.
The Local Area Connection Properties window appears.
5. Select the Internet Protocol (TCP/IP) and click the Properties Button.
1 After connecting the Ethernet port, you have to install and configure your Ethernet Port. For detailed instructions, see the Ethernet
Configuration Guide (L
