Operating Your Video Matrix Switcher
20
7.1.1 Viewing the Display
Figure 11 shows the output-input matrix on the LCD display. The LCD display can
show only 13 out of the 16 available matrix combinations at once. To view any of
the matrix combinations use the ◄ or the ► buttons on the front panel to shift the
sliding window to the right or left.
This sliding window functionality is enabled when:
• The switcher is in between operations 1
• Recalling a setup using the ◄ or ► buttons
When entering an output/input combination, the contents of the LCD display
automatically shift to indicate the current status of the selected output.
7.2 Using the Selector Buttons
For numbers between 1 and 9, the VS-1616D can handle two digit numbers as well
as single digit numbers. When entering a single digit number (for example 5), you
can either press 0 followed by 5, or 5 followed by ENT.
Pressing 00 (or 0, ENT) is only relevant for an input and is used to disconnect the
currently entered output number from the input.
For example, the following display indicates that outputs 8 and 12 are
disconnected from any input (note that the corresponding inputs in the second
line are blank):
06 07 08 09 10 11 12 13
12 08 10 14 13 06
The ESC button is used to cancel an operation without affecting the current status.
For example, if you enter an incorrect number by mistake, press the ESC button to
cancel the operation.
Note: At any stage, if no button is pressed within approximately 15 seconds, the
automatic timeout causes the VS-1616D to exit the operation and revert to the
output/input display.
7.3 Confirming Actions
You can choose to work in the At Once (default 2
In the At Once mode:
) or the Confirm mode.
• The TAKE button does not light
1 Waiting for its next operation while all previous operations are complete or cancelled
2 For all actions except storing/recalling
