Using the Configuration Menus
26
8.1 Using the Setup Menu
The Setup Menu provides access to settings that are regularly changed and
comprises the following options:
• 1: inXX=>ALL, switching one input to all outputs (see Section 8.1.1
• 3: outXX=OFF, turning off an output (see
)
Section 8.1.2
• 7: EDID, assignment to an output (see
)
Section 8.1.3
• 9: Delay setting for an output (see
)
Section 8.1.4
• 4: store setup XX, storing the setup in a preset (see
)
Section 8.1.5
• 6: recall setup XX, recalling a preset (see
)
Section 8.1.6
8.1.1 Setup Menu—1: inXX=>ALL, Switching one Input to all Outputs
)
This option switches one input to all outputs.
To switch one input to all outputs:
1. Press MENU.
The Setup Menu options are displayed.
2. Press 1 (ALL) on the numeric keypad (see Figure 2 ).
The following is displayed:
in__ => ALL
3. Using the numeric keys, enter the input to be switched to all outputs.
The TAKE button flashes.
4. Press TAKE.
The selected input is switched to all outputs.
The display reverts to the output/input display showing that the selected input
is switched to all outputs.
8.1.2 Setup Menu—3: outXX=>OFF, Turning an Output Off
This option turns an output off.
To turn an output off:
1. Press MENU.
The Setup Menu options are displayed.
2. Press 3 (OFF) on the numeric keypad (see Figure 2 ).
The following is displayed:
out__ => OFF
3. Using the numeric keys, enter the output to be turned off.
The TAKE button flashes.
4. Press TAKE.
The selected output is turned off.
The display reverts to the output/input display showing that the selected
output is turned off with the input being blank.
