AT-S39 User’s Guide
144
3. Type 1 to select Enable/Disable VLANs.
The VLAN Support window in Figure 46 is displayed.
Figure 46 VLAN Support Window
The prompt enclosed in asterisks gives the current status of the
VLANs.
4. Type E to enable the VLANs or D to activate the Basic VLAN Mode.
5. Press any key.
6. Type R to select Return to Previous Menu.
7. Type S to select Save Configuration Changes.
8. Reset the switch using the Reset Switch option in the Administration
Menu or the reset button on the back of the unit.
A change to VLAN status is not activated until you reset the switch.
Allied Telesyn Ethernet Switch AT-8024
Login Session: Manager
VLAN Support
** VLANs are globally Enabled **
E - Enable VLANs Globally
D - Disable VLANs Globally
S - Save Configuration Changes
R - Previous Menu
Enter your selection?
