AT-S39 User’s Guide
132
Modifying a VLAN
Note
You need to know the VID of the VLAN you want to modify in order
to perform this procedure. To view the VLAN VIDs, refer to the
procedure Displaying VLAN Information on page 135.
To modify a VLAN, perform the following procedure:
1. From the Main Menu, type 2 to select VLAN Menu.
2. From the VLAN Menu, type 2 to select Virtual LAN Definitions.
3. From the Virtual LAN Definitions menu, type 2 to select Modify a
VLAN.
The Modify a VLAN window in Figure 41 is displayed.
Figure 39 Modifying a VLAN Menu
4. Type 1 to select VLAN ID (VID).
The following prompt is displayed:
Enter new value -> [1 to 4096] ->
5. Enter the VID of the VLAN you want to modify. Press Return.
The Modify a VLAN window for the selected VLAN is displayed. This
window contains all relevant information about the VLAN.
6. Change the VLAN’s information as desired.
The menu selections in the window are described below:
1 - VLAN Name
Use this selection to change a VLANs name. The name can be from
one to fifteen characters in length. The name should reflect the
Allied Telesyn Ethernet Switch AT-8024
Login Session: Manager
Modify VLAN
1 - VLAN ID (VID) ........
S - Save Configuration Changes
R - Return to Previous Menu
Enter your selection?
