5. To configure just one port, enter the same port number here as you
entered in the previous step. To configure a range of ports, enter the
last port of the range.
The RSTP Port Configuration menu in Figure 32 is displayed.
Figure 32 Configure RSTP Port Settings Menu
6. Adjust the settings as needed. The parameters are explained below.
1 - Port Priority
This parameter is used as a tie breaker when two or more ports are
determined to have equal costs to the root bridge. The range is 0
to 240 in increments of 16. The default value is 8 (priority value
128). For a list of the increments, refer to Table 7, RSTP Port
Priority Value Increments on page 95.
2 - Port Cost
The spanning tree algorithm uses the cost parameter to decide
which port provides the lowest cost path to the root bridge for
that LAN. The range is 0 to 20 000 000. The default setting is Auto-
detect, which sets port cost depending on the speed of the port.
Default values are 2 000 000 for 10 Mbps ports, 200 000 for a 100
Mbps ports, and 20 000 for one gigabit ports.
3 - Point-to-Point
This parameter defines whether the port is functioning as a point-
to-point port. For an explanation of this parameter, refer to Point-
to-Point Ports and Edge Ports on page 97.
Allied Telesyn Ethernet Switch AT-8024
Login Session: Manager
Configure RSTP Port Settings
Configuring Ports 4 to 4
1 - Port Priority ...... 128
2 - Path Cost .......... Auto Update
3 - Point-to-Point ..... Auto Detect
4 - Edge Port .......... Yes
M - MCHECK (Check Migration to RSTP on Selected Ports)
S - Save Configuration Changes
R - Return to Previous Menu
Enter your selection?
