Web-based Management
88
Address Table Configuration
The Address Table contains the unicast MAC addresses and VLAN
identifier associated with each port (that is, the source port associated
with the address and VLAN). You can also clear the entire address table,
or information associated with a specific port, address, or VLAN
identifier; or set the aging time for deleting inactive entries. The
information displayed in the Address Table is indicated in the following
figure and table.
Aging Time (10-415):
Dynamic Address Counts:
Static Address Counts:
<
Remove
Clear Table
Address Address Table Sort Key:
300 seconds
115
0
000024-B32883, VLAN 1, Unit 1, Port 7, Dynamic
0000E2-12F9F8, VLAN 1, Unit 1, Port 7, Dynamic
0000E2-20C3D5, VLAN 1, Unit 1, Port 7, Dynamic
0000E2-16C582, VLAN 1, Unit 1, Port 7, Dynamic
0000E2-000678, VLAN 1, Unit 1, Port 7, Dynamic
0000E2-2174D0, VLAN 1, Unit 1, Port 7, Dynamic
0000E8-008907, VLAN 1, Unit 1, Port 7, Dynamic
0000E8-B235D5, VLAN 1, Unit 1, Port 7, Dynamic
0000E8-1012D5, VLAN 1, Unit 1, Port 7, Dynamic
0000E8-B21002, VLAN 1, Unit 1, Port 7, Dynamic
0000E8-24C346, VLAN 1, Unit 1, Port 7, Dynamic
MAC
Address
VLAN
(1-2048)
Unit
Port
1
1
Parameter Description
Aging Time Time-out period in seconds for aging out dynamically learned
forwarding information. The range is 10 - 415 seconds; and the
default is 300 seconds.
Dynamic Address Count The number of dynamically learned addresses.
Static Address Count The number of statistically configured addresses
Address Table Sort Key The system displays the MAC address of each node, the switch unit
and the port whose address table includes this MAC address, the
associated VLAN(s), and the address status (i.e., dynamic or static)
Address Table All entries, sorted by address or VLAN ID.
New Static Address Use these fields to add or remove a static entry to the address
table. Indicate the address, stack unit, port and VLAN group when
adding a new entry.
Add/Remove Adds/removes selected address.
Clear Table Removes all addresses from the address table.
