AT-S29 Management Software User’s Guide
23
Menu Description
System Information Menu:
System Information Provides basic system description, including contact information.
Switch Information Shows hardware/firmware version numbers, power status, and
expansion modules used in the stack.
Management Setup Menu:
Network Configuration Includes IP setup, Ping facility, HTTP (Web Agent) setup, Telnet
enable, and MAC address.
Serial Port Configuration Sets communication parameters for the serial port, including
management mode, baud rate, console time-out, and screen data
refresh interval.
SNMP Configuration Activates traps; and configures communities and trap managers.
Console Login
Configuration Sets the user names and passwords for system access, as well as the
invalid password threshold and lockout time.
TFTP Download Downloads new version of firmware to update your system (in-
band).
Device Control Menu:
Port Configuration Enables any port, enables/disables flow control, and sets
communication mode to auto-negotiation, full duplex or half
duplex.
Port Information Displays operational status, including link state, flow control
method, and duplex mode.
Spanning Tree
Configuration Enables Spanning Tree Algorithm; also sets parameters for hello
time, maximum message age, switch priority, and forward delay; as
well as port priority and path cost.
Spanning Tree
Information Displays full listing of parameters for Spanning Tree Algorithm.
Mirror Port Configuration Specifies the source and target ports for mirroring.
Port Trunking
Configuration Specifies ports to group into aggregate trunks.
IGMP Configuration Configures IGMP multicast filtering.
Extended Bridge
configuration Displays/configures extended bridge capabilities provided by this
switch, including support for traffic classes, GMRP multicast
filtering, and VLAN extensions.
802.1P Configuration Configures default port priorities and queue assignments.
