Page 133
133
Appendix B
Pin Assignments
DB9 Serial Port Pin Description
The DB-9 serial port on the panel of the Network Management
Module is used to connect the switch to a management device. The
on-board menu-driven configuration program can be accessed from
a terminal, a PC running a terminal emulation program, or from a
remote location via a modem connection. The pin assignments used
to connect various device types to the switch’s management port are
provided in the following tables.
Pin 1
Pin 9
