AT-S29 Management Software User’s Guide
55
Configuring
Bridge MIB
Extensions
The Bridge MIB includes extensions for managed devices that support
Traffic Classes, Multicast Filtering and Virtual LANs. To configure these
extensions, use the Extended Bridge Configuration screen as shown
below:
Extended Bridge Configuration
============================
Bridge Capability : (Read Only)
Extended Multicast Filtering Services : NO
Traffic Classes
: YES
Static Entry Individual Port : YES
VLAN Learning : IVL
Configurable PVID Tagging : YES
Local VLAN Capable : NO
Bridge Settings :
Traffic Class : FALSE
GMRP : DISABLED
GVRP : DISABLED
Use or arrow keys to move. to scroll
option.
Parameter Description
Bridge Capability
Extended Multicast
Filtering Services Enables filtering of individual multicast addresses based on GMRP
(GARP Multicast Registration Protocol). Note that this function is not
available for the current firmware release.
Traffic Classes Provides mapping of user priorities to multiple traffic classes. (Refer to
802.1p Configuration.)
Static Entry Individual
Port Enables static filtering for unicast and multicast addresses. (Refer to
the Network Monitor Menu / Static Unicast Address Table
Configuration and Static Multicast Address Table Configuration.)
VLAN Learning This switch uses Independent VLAN Learning (IVL), whereby each port
maintains its own VLAN filtering database.
Configurable PVID
Tagging Allows you to override the default PVID setting (Port VLAN ID used in
frame tags) and its egress status (VLAN-Tagged or Untagged) on each
port. (Refer to 802.1Q VLAN Port Configuration.
Local VLAN Capable This switch does not support multiple local bridges (that is, multiple
Spanning Trees).
