Web-based Management
100
VLAN Current
Table
This screen shows the current port members of each VLAN and whether
or not the port supports VLAN tagging. Ports assigned to a large VLAN
group that crosses several switches should use VLAN tagging. However,
if you just want to create a small port-based VLAN for one or two
switches, you can assign ports to the same untagged VLAN. The current
configuration is shown in the following screen.
Parameter Description
VLAN Entry Delete
Count The number of times a VLAN entry has been
deleted from this table.
VLAN ID The ID for the VLAN currently displayed.
Up Time at
Creation The value of sysUpTime (System Up Time) when
this VLAN was created.
Status Shows how this VLAN was added to the switch:
Dynamic GVRP: Automatically learned via GVRP.
Permanent: Added as a static entry.
Parameter Description
Egress Ports Shows the ports which have been added to the
displayed VLAN group.
Untagged Ports Shows the untagged VLAN port members.
Up Time at Creation 0 d 0 h 0 min 0 s
Status Dynamic GVRP
VLAN Entry Delete Count: 0
VLAN ID: 1
Unit 1, Port 1
Unit 1, Port 2
Unit 1, Port 3
Unit 1, Port 4
Unit 1, Port 5
Unit 1, Port 6
Unit 1, Port 7
Unit 1, Port 8
Egress Ports Untagged Ports
Unit 1, Port 1
Unit 1, Port 2
Unit 1, Port 3
Unit 1, Port 4
Unit 1, Port 5
Unit 1, Port 6
Unit 1, Port 7
Unit 1, Port 8
