Web-based Management
104
VLAN Port
Configuration
Use this screen to configure port-specific settings for IEEE 802.1Q VLAN
features:
Port PVID (1-2048) Type
Acceptable Frame
Filtering
Ingress
Status
GVRP
Registration
GVRP Failed
Origin
GVRP PDU
Enable Enable 00-00-00-00-00-00 All 1 0 1
Enable Enable 00-00-00-00-00-00 All 1 0 2
Enable Enable 00-00-00-00-00-00 All 1
0 3
Enable Enable 00-00-00-00-00-00 All 1
0 4
Parameter Description
PVID The VLAN ID assigned to untagged frames
received on this port. Use the PVID to assign
ports to the same untagged VLAN.
Acceptable Frame
Type
1
1. 1: This control does not affect VLAN independent BPDU frames, such as GVRP or STP.
However, it does affect VLAN dependent BPDU frames, such as GMRP.
This switch accepts “All" frame types, including
VLAN tagged or VLAN untagged frames. Note
that all VLAN untagged frames received on this
port are assigned to the PVID for this port.
Ingress Filtering
1
If set to "True," incoming frames for VLANs which
do not include this port in their member set will
be discarded at the inbound port.
GVRP Status Enables or disables GVRP for this port. When
disabled, any GVRP packets received on this port
will be discarded and no GVRP registrations will
be propagated from other ports.
Note that GVRP must be enabled for the switch
before this setting can take effect. (See Device
Control Menu / Extended Bridge Configuration.)
GVRP Failed
Registrations The total number of failed GVRP registrations, for
any reason, on this port.
GVRP Last PDU
Origin The Source MAC Address of the last GVRP
message received on this port.
