Using the System Configuration Program
64
Monitoring the Switch
The Network Monitor Menu provides access to port statistics, RMON
statistics, IP multicast addresses, and the static (unicast) address table.
Each of the screens provided by these menus is described in the
following sections.
Network Monitor Menu
====================
Port Statistics ...
RMON Statistics ...
Unicast Address Table ...
Multicast Address Registration Table ...
IP Multicast Registration Table ...
Static Unicast Address Table Configuration ...
Static Multicast Address Table Configuration ...
Use or arrows keys to move. to select.
Parameter Description
Port Statistics Displays statistics on network traffic passing through
the selected port.
RMON Statistics Displays detailed statistical information for the selected
port such as packet type and frame size counters.
Unicast Address
Table Provides full listing of all unicast addresses stored in the
switch, as well as sort, search and clear functions.
Multicast Address
Registration Table
1
Displays the ports that belong to each GMRP Muticast
group.
IP Multicast
Registration Table Displays the ports that belong to each IP Muticast
group.
Static Unicast
Address Table
Configuration Allows you to display or configure static unicast
addresses.
Static Multicast
Address Table
Configuration
1
Allows you to display or configure static GMRP
multicast addresses.
1. Not implemented in this firmware release.
