Web-based Management
82
IP Configuration
Use the IP Configuration screen to set the bootup option, configure the
IP addresses for the agent module, or set the number or concurrent
Telnet sessions allowed. The screen shown below is described in the
following table.
IP State:
User-Configured
IP Address:
Subnet Mask:
Gateway IP Address:
MAC Address:
Number of Telnet sessions (1-4):
10.1.0.1
255.255.255.0
00-30-84-E8-93-AE
10.1.0.254
4
Parameter Default Description
IP State USER-CONFIG Specifies whether IP functionality is enabled via manual
configuration, or set by Boot Protocol (BootP). Options include:
❑ USER-CONFIG - IP functionality is enabled based on the
default or user specified IP Configuration. (This is the
default setting.).
❑ BootP Get IP - IP is enabled but will not function until a
BootP reply has been received. BootP requests will be
periodically broadcast by the switch in an effort to learn
its IP address. (BootP values include the IP address, default
gateway, subnet mask, TFTP boot file name, and TFTP
server IP.)
IP Address 10.1.0.1 IP address of the agent you are managing. The Agent Module
supports SNMP over UDP/IP transport protocol. In this
environment, all systems on the Internet, such as network
interconnection devices and any PC accessing the Agent
Module are assigned an IP address. Valid IP addresses consist of
four numbers, of 0 to 255, and separated by periods. Anything
outside of this format will not be accepted by the configuration
program.
Subnet
Mask 255.255.255.0 Subnet mask of the agent you have selected. This mask
identifies the host address bits used for routing to specific
subnets.
Gateway IP
Address 0.0.0.0 Gateway used to pass trap messages from the switch’s agent to
the management station. Note that the gateway must be
defined if the management station is located in a different IP
segment.
