AT-S29 Management Software User’s Guide
41
Configuring Port
Parameters
Use the Port Configuration menus to configure any port or module on
the switch.
Note
Auto-negotiation is not available for 100Base-FX ports.
Port Configuration: Unit 1 Port 1-12
=====================
Port
Type
Admin
Flow
Speed and
Control
Duplex
-----------------------------------------------------
1
10/100TX
ENABLED
ENABLED
10-HALF
2
10/100TX
ENABLED
DISABLED 100-FULL
3
10/100TX
ENABLED
ENABLED
AUTO
4
10/100TX
ENABLED
DISABLED AUTO
5
10/100TX
ENABLED
ENABLED
10-FULL
6
10/100TX
ENABLED
DISABLED 100-HALF
7
10/100TX
ENABLED
DISABLED AUTO
8
10/100TX
ENABLED
ENABLED
AUTO
9
10/100TX
ENABLED
ENABLED
AUTO
10
10/100TX
ENABLED
ENABLED
AUTO
11
10/100TX
ENABLED
ENABLED
AUTO
12
10/100TX
ENABLED
ENABLED
AUTO
PAGE> Use Parameter Default Description Type Shows port type as: 10Base-T/100Base-TX 100FX : 100Base-FX 1000SX : 1000Base-SX 1000LX : 1000Base-LX Admin Enabled Allows you to disable a port due to abnormal behavior (e.g., Flow Control Disabled Used to enable or disable flow control. Flow control can eliminate Speed and Auto Used to set the current port speed, duplex mode, and auto-
10/100TX:
excessive collisions), and then re-enable it after the problem has
been resolved. You may also disable a port for security reasons.
frame loss by "blocking" traffic from end stations or segments
connected directly to the switch when its buffers fill. Back
pressure is used for half duplex and IEEE 802.3x for full duplex.
Note that flow control should not be used if a port is connected to
a hub.
Duplex
negotiation.
