AT-S29 Management Software User’s Guide
63
802.1Q VLAN Port Configuration
Use this screen to configure port-specific settings for IEEE 802.lQ VLAN
features.
Parameter
Description
PVID
The VLAN ID assigned to untagged frames received on this port. Use the
PVID to assign ports to the same untagged VLAN.
Acceptable Frame
Type
1
2
This switch accepts “All" frame types, including VLAN tagged or VLAN
untagged frames. Note that all VLAN untagged frames received on this
port are assigned to the PVID for this port.
Ingress Filtering
1
If set to "True," incoming frames for VLANs which do not include this port
in their member set will be discarded at the inbound port.
GVRP Status
Enables or disables GVRP for this port. When disabled, any GVRP packets
received on this port will be discarded and no GVRP registrations will be
propagated from other ports.
Note that GVRP must be enabled for the switch before this setting can take
effect. (See Device Control Menu / Extended Bridge Configuration.)
GVRP Failed
Registrations
The total number of failed GVRP registrations, for any reason, on this port.
GVRP Last PDU
Origin
The Source MAC Address of the last GVRP message received on this port.
1. This control does not affect VLAN independent BPDU frames, such as GVRP or STP. However, it does affect VLAN dependent BPDU frames,
such as GMRP.
2. Not implemented in this firmware release.
802.lQ VLAN Port Configuration : Unit 1 Port 1 - 12
=================================================
Port PVID
Acceptable
Ingress
GVRP
GVRP Failed
GVRP Last
Frame Type
Filtering
Status
Registrations PDU Origin
--------------------------------------------------------------------
1 1
All
FALSE
DISABLED
000-00-00-00-00-00
2 1
All
FALSE
DISABLED
000-00-00-00-00-00
3 1
All
FALSE
DISABLED
000-00-00-00-00-00
4 1
All
FALSE
DISABLED
000-00-00-00-00-00
5 1
All
FALSE
DISABLED
000-00-00-00-00-00
6 1
All
FALSE
DISABLED
000-00-00-00-00-00
7 1
All
FALSE
DISABLED
000-00-00-00-00-00
8 1
All
FALSE
DISABLED
000-00-00-00-00-00
9 1
All
FALSE
DISABLED
000-00-00-00-00-00
101
All
FALSE
DISABLED
000-00-00-00-00-00
111
All
FALSE
DISABLED
000-00-00-00-00-00
121
All
FALSE
DTSABLED
000-00-00-00-00-00
Use
