Using the System Configuration Program
62
Using the System Configuration Program
For example, the following screen displays settings for VLAN 2, which
includes tagged ports 1-6, and forbidden port 12. (Note that the dashed
lines show that there are no switch units in this system other than Unit
1.)
802.1Q VLAN Static Table Information
======================================
VID VLAN Name Row Status
--------------------------------------
2
RD Active
Unit Egress Ports Forbidden Egress Ports
1. 111111000000 000000000000 0---000000000001 000000000000 0---
2. ------------ ------------ ---------------- ------------ ----
3. ------------ ------------ ---------------- ------------ ----
4. ------------ ------------ ---------------- ------------ ----
VID : 2
[Show]
[More]
[New]
Use or arrows keys to move, other keys to make changes.
to select.
