Misc.

1.760

1.013

MAX.

1.000

MAX.

10 Pin Straight Cable

(951, 952, & 953 Connector Option E)

4, 5 & 6 Pin Micro 12mm

Euro Straight Cable

(955, 956, 952A, 953)

1.69

.58

.37

10 Pin Straight Cable

(955DQ Connector Option H)

(OBSOLETE)

4, 5 & 6 Pin Micro 12mm

Euro Right Angle

(955, 956, 952A, 953)

Universal Mounting Kit

P/N: SD0441300

2.25

.55

1.00

2 Pin Mini 16mm

Euro Molded Cable

(950IS)

12 Pin Micro 12mm

Euro Straight Cable

(955DQ Connector Option E)

Cable Termination Kit

951, 952 Digital P/N: SD0443800L25

951, 952 Analog P/N: SD0443803L25

953 Digital P/N: SD0443804L25

1.965

.450

.812

1.046

MAX.

10 Pin Right Angle Cable

(951, 952, & 953 Connector Option E)

Cable Accessories
