952
Part Numbering
952QD 0120
Stroke Length
Insert stroke length to 0.1 inch.
Enter as a four-place number.
Example: A 12.0” stroke enters as
0120. To convert metric strokes,
multiply millimeter value by
0.03937 for inch value.
E X X
Null Zone
X Standard 2 inches.
N_
Insert non-standard Null Zone over
2 inches. (Add non-standard portion
of Null length to stroke length to
calculate list price)
Connector Option
E Environmental MS connector*
C_
Potted pigtail cable assembly, insert
pigtail length in feet. Example: C6 = 6
foot cable.
Dead Band
X Standard 2.5 inches.
D_
Insert non-standard Dead Band over
2.5 inches. (add non-standard portion
of Dead Band length to stroke length
to calculate list price)
* If option E (environmental connector) is selected, mating
connector and/or cable assembly must be ordered separately.
Quadrature
BlueOx
1000
Output Resolution
Cycles per inch, maximum internal
resolution is 0.001 inches 1000 standard
(available range is 0001 through 9999)
M1 F7 E
Input
E
Sinking
(typically used with
sourcing output type)
C
Sourcing
(typically used with
sinking output type)
T TTL Level
Output Mode
M1
X1 quadrature, consult factory
for other output modes
Quadrature Cycle Output
Frequency Range
F1 10 kHz
F2 25 kHz
F3 50 kHz
F4 75 kHz
F5 100 kHz
F6 150 kHz
F7 250 kHz
F8 500 kHz
F9 1 MHz
V X D
Output Drivers
D Differential RS422 line driver, TTL compatible
L
Differential line driver
10 to 30 VDC, V out = V in (LDT Power) -1 Volt
Options
X None
Zero Offset Storage
V Volatile (non retentive)
N
Nonvolatile (retentive, 100,000
storage cycles maximum)
952QD BlueOx Magnetostrictive
LDT with Quadrature Output
