Misc.

.19 THRU

BOLT CIRCLE.

(4) PLACES AS SHOWN

EQ SPACED ON A .937

MATERIAL: ALUMINUM

.530

1.290

.250

P/N: M0822400

Non-Ferrous Spacer for 4 Hole Magnet

1.29

.31

.53

.331 TYP.

.662 TYP.

.187

4 PLACES

Standard P/N: SD0400800

Stainless Steel P/N: SD0480900

Standard 4 Hole Magnet

(2) PLACES

.234

.812

.187

.53

.31

MAT’L.: ALUMINUM

P/N: SD0403900

Aluminum Split Magnet

P/N: M0750500

Non-Ferrous Spacer for Split Magnet

.234

.406

.812

.19 DIA. THRU

(2) PLACES

.56

SLOT

1.290

.25

MAT’L.: ALUMINUM

Rod Magnets
