953
NOTE: Metric LDTs cannot be used with standard 950MD housings.
Consult factory.
Digital, VP (PWM) Part Numbering
Digital, CP and RS Part Numbering
953D
0120
RS
Stroke Length
Insert stroke length to 0.1 inch. Enter as a four-place number.
Example: A 12.0” stroke enters as 0120.
OR
Insert stroke in millimeters to 1mm. Enter as a four-place number.
Example: 305mm stroke entered as 0305M. Metric length includes
metric mounting, M18x1.5. Unless Specified Otherwise
Output
CP
Control Pulse
RS
RS-422 Start/Stop Pulse
TP
TTL Level Start/Stop
Typically used to replace
neutered style probes.
S
X
X
X
Options
X
None
S
Stainless Steel cover and
connector. Only available
with connector options S,
C, and H.
Connector Option
S
Standard 5 Pin, 12mm Euro
C_
Integral Cable Assembly. Insert
length in feet. Example: C6 = 6
foot cable.
M
6 Pin DIN, MTS Style D60
B
8 Pin DIN, Balluff S32
E
Environmental 10 Pin MS
Connector compatible w/951
& 952 LDTs w/connector
option “E”.
H_
High Temp., Integral cable
assembly 200º C Teflon Cable.
Insert length in feet. Example:
H6= 6 foot High Temp Teflon
Cable.
Optional Housing Style
- Mounting Threads
Blank
Raised face hex
base (standard) -
Threads will be the
same as “Units of
Measure” unless
specified otherwise.
R
US Threads with
raised face hex
base
F
US Threads with
flat face hex base
M
Metric Threads with
raised face hex
base
N
Metric Threads with
flat face hex base
C
Sensor cartridge
only - No hex base
953D
0120
VP
I
Stroke Length
Insert stroke length to 0.1 inch. Enter as a
four-place number. Example: A 12.0” stroke
enters as 0120.
OR
Insert stroke in millimeters to 1mm. Enter as
a four-place number. Example: 305mm stroke
entered as 0305M. Metric length includes
metric mounting, M18x1.5. Unless Specified
Otherwise
Output
VP
Variable Pulse
S
X
X
Interrogation Mode
I
Internal Interrogation
E
External Interrogation
001
Number of Recirculations
001
001 (Standard) to 255
X
Options
X
None
S
Stainless Steel cover and
connector. Only available
with connector options S,
C, and H.
Connector Option
S
Standard 6 Pin, 12mm Euro
C_
Integral Cable Assembly. Insert length in
feet. Example: C6 = 6 foot cable.
M
6 Pin DIN, MTS Style D60
B
8 Pin DIN, Balluff S32
E
Environmental 10 Pin MS Connector
compatible w/951 & 952 LDTs w/
connector option “E”.
H
High Temp., Integral cable assembly
200º C Teflon Cable. Insert length in
feet. Example: H6= 6 foot High Temp
Teflon Cable.
Optional Housing Style
- Mounting Threads
Blank
Raised face hex
base (standard) -
Threads will be the
same as “Units of
Measure” unless
specified otherwise.
R
US Threads with
raised face hex
base
F
US Threads with
flat face hex base
M
Metric Threads with
raised face hex
base
N
Metric Threads with
flat face hex base
C
Sensor cartridge
only - No hex base
Units of Measure
Blank
Inches.
M
Metric
Units of Measure
Blank
Inches.
M
Metric
Dead Band
X
Standard 2.5 inches.
D
Insert non-standard Dead
Band (2.25” Minimum)
This value is called out in
inches regardless of units
of measure (i.e. 2.25”
Dead Band = D2.25)
Null Zone
X
Standard 2 inches.
N
Insert non-standard Null Zone
(1.5” Minimum).
This value is called out in inches
regardless of units of measure
(i.e. 1.5” Null Zone = N1.5)
Dead Band
X
Standard 2.5 inches.
D_
Insert non-standard Dead Band
(2.25” Minimum)
This value is called out in inches
regardless of units of measure
(i.e. 2.25” Dead Band = D2.25)
Null Zone
X
Standard 2 inches.
N
Insert non-standard Null Zone (1.5” Minimum).
This value is called out in inches regardless of
units of measure (i.e. 1.5” Null Zone = N1.5)
953A/D/SSI VMAX
™
LDT
