APPENDIX “D” - GEMINI 3300 BATCH COUNTER MODE FUNCTION COMMAND CODE SUMMARY
-40-
CODE MODE DESCRIPTION COMMENTS
62 PROCESS COUNTER RESET ACTION & PRESET TRACKING MODES
- (+) Preset Tracking Disabled
- (-) Preset Tracking Enabled Preset 1 tracks Preset 2
+/-1 Manual Reset to Zero
+/-2 Manual Reset to Preset
+/-3 Auto Reset to Zero after Timed Output 2
+/-4 Auto Reset to Preset after Timed Output 2
+/-5 Auto Reset to Zero at Preset 2
+/-6 Auto Reset to Preset at Zero
63 BATCH COUNTER RESET ACTION MODES
1 Manual Reset to Zero
2 Manual Reset to Preset
3 Auto Reset to Zero after Timed Output B
4 Auto Reset to Preset after Timed Output B
5 Auto Reset to Zero at Preset B
6 Auto Reset to Preset at Zero
64 BATCH OUTPUT TERMINATION MODES
- (+) Normal Phase Output normally “OFF”, turns “ON” at preset.
- (-) Reverse Phase* Output normally “ON”, turns “OFF” at preset.
+/-3 Terminate at Manual Reset
+/-4 Terminate at Manual Reset End
+/-5 Terminate after Timed Output B
65 TIMED BATCH OUTPUT VALUE Range 0.01 to 599.99 sec.
*Polarity sign is displayed in front of the identifier, a (-) sign is displayed, a (+) sign is not.
