[62 4] AUTOMATIC RESET TO PRESET 2 AFTER TIMED OUTPUT 2 -
The Process Counter automatically resets to Preset 2 when Timed Output 2
ends. The “Output 2 Termination Mode” should be programmed for timed
output operation, [54 5], when in this mode. Preset tracking is disabled.
[62 5] AUTOMATIC RESET TO ZERO AT THE BEGINNING OF TIMED
OUTPUT 2 (AT PRESET 2) - In this reset mode, the Process Counter will
automatically reset to zero at the beginning of Timed Output 2 (at Preset
2). The Timed Output 2 Value (Code 55) must be shorter than the time
required for the counter to count to the Preset 2 Value, otherwise, Output 2
will appear to be latched on. The “Output 2 Termination Mode” should be
programmed for timed output operation, [54 5], when in this mode. Preset
tracking is disabled.
[62 6] AUTOMATIC RESET TO PRESET 2 AT THE BEGINNING OF
TIMED OUTPUT 2 (AT ZERO) - In this reset mode, the Process Counter will
automatically reset to Preset 2 at the beginning of Timed Output 2 (at zero).
The Timed Output 2 Value (Code 55) must be shorter than the time required
for the counter to count to zero, otherwise, Output 2 will appear to be latched
on. The “Output 2 Termination Mode” should be programmed for timed
output operation, [54 5], when in this mode. Preset tracking is disabled.
[62 -1]
[62 -2]
[62 -3] These modes are the same as above with the exception
[62 -4] that Preset Tacking is enabled.
[62 -5]
[62 -6]
CODE 63 - BATCH COUNTER RESET ACTION MODES
The “Batch Counter Reset Action Mode” determines how the Batch Counter
can be reset and the type reset action that will occur. In the manual reset modes, the
Batch Counter can only be reset by activation of the Reset button, reset terminal
(See “Reset Button & Terminal Actuation Modes” - Code 61), 2-button reset, or
through serial communications. In the “Auto Reset” modes, the Batch Counter can
be reset manually and can also be reset when the Batch Counter reaches the Batch
Preset value or zero (reset to Preset modes), or after the Batch Timed Output.
-13-
[63 1] MANUAL RESET TO ZERO - Manual reset to zero is accomplished
by pulling the “RST.” terminal to “COMMON” or, if the front panel reset is
enabled, by pressing the front panel reset button, or by using the “Two
Button Reset” (pressing the “E” key and the “2” key).
[63 2] MANUAL RESET TO BATCH PRESET - Manual reset to Batch
Preset is accomplished by pulling the “RST.” terminal to “COMMON” or,
if the front panel reset is enabled, by pressing the front panel reset button,
or by using the “Two Button Reset” (pressing the “E” key and the “2” key).
[63 3] AUTOMATIC RESET TO ZERO AFTER BATCH TIMED OUTPUT
- The Batch Counter automatically resets to zero when Batch Timed Output
ends. The “Batch Output Termination Mode” should be programmed for
timed output operation, [64 5], when in this mode.
[63 4] AUTOMATIC RESET TO BATCH PRESET AFTER BATCH TIMED
OUTPUT - The Batch Counter automatically resets to Batch Preset when
Batch Timed Output ends. The “Batch Output Termination Mode” should be
programmed for timed output operation, [64 5], when in this mode.
[63 5] AUTOMATIC RESET TO ZERO AT THE BEGINNING OF BATCH
TIMED OUTPUT (AT BATCH PRESET) - In this reset mode, the Batch
Counter will automatically reset to zero at the beginning of Batch Timed
Output (at Batch Preset). The Batch Timed Output Value (Code 65) must
be shorter than the time required for the counter to count to the Batch Preset
Value, otherwise, the Batch Output will appear to be latched on. The
“Batch Output Termination Mode” should be programmed for timed
output operation, [64 5], when in this mode.
[63 6] AUTOMATIC RESET TO BATCH PRESET AT THE BEGINNING OF
BATCH TIMED OUTPUT (AT ZERO) - In this reset mode, the Batch Counter
will automatically reset to Batch Preset at the beginning of Batch Timed Output
(at zero). The Batch Timed Output Value (Code 65) must be shorter than the
time required for the counter to count to zero, otherwise, the Batch Output will
appear to be latched on. The “Batch Output Termination Mode” should be
programmed for timed output operation, [64 5], when in this mode.
CODE 64 - BATCH OUTPUT TERMINATION MODES
The Gemini 3300 has three “Batch Output Termination Modes”, which
control the way Batch Output (OB) will terminate or reset. A Batch Output
response will occur when the Batch Counter reaches the Batch Preset value or
zero. In all modes, the Batch Output will terminate immediately when the
Batch Counter is manually reset.
