CODE 64 - BATCH OUTPUT TERMINATION MODES (Cont’d)
A reverse phase mode is available on the Gemini 3300. This refers to the
complementing of the logic state of the output. With normal phase operation,
when the Batch counter value reaches the Batch Preset, the Batch Output will
turn on. The reset condition of the Batch Output is output off. In reverse phase
operation, the Batch Output turns off when the Batch Preset is reached. The
reset condition of the Batch Output is output on. A “-” sign in front of the
mode identifier will provide for reverse phase operation. The absence of a “-”
sign will indicate normal phase operation.
[64 3] TERMINATE AT MANUAL RESET - The Batch Output (OB)
activates when the Batch Counter reaches the Batch Preset value or zero. In
this mode, once the Batch Output is activated, it does not deactivate until
the moment a manual reset of the Batch Counter occurs. The Batch Output
is set for normal phase operation.
[64 4] TERMINATE AT MANUAL RESET END - This mode is like the
preceding, except the Batch Output (OB) deactivates when manual reset
ends. The Batch Output is set for normal phase operation.
[64 5] TERMINATE AFTER TIMED BATCH OUTPUT - Once the Batch
Output (OB) has been activated, it will deactivate after the predetermined
length of time (Code 65) has expired. Manual reset will override the
timed output and reset the Batch Output. The Batch Output is set for
normal phase operation.
[64 -3] These modes are the same as above with the exception
[64 -4] that the output is set for reverse phase operation.
[64 -5]
CODE 65 - BATCH TIMED OUTPUT VALUE
The Gemini 3300 has the capability of varying the Batch Timed Output
Value from 0.01 second to 599.99 seconds. When the code is entered, instead
of a single mode identifier digit being displayed, six digits will be shown.
Refer to “Programming the Presets, Scale Factor, Timed Outputs & Counter
Load Values” section for more details about entering. The timed output will
be terminated if the Batch Counter is manually reset.
Note: A Timed Output Value of zero cannot be programmed into the Gemini 3300.
If a value of 0 is entered into the display and the “E” key is pressed, the unit will
not enter the 0, but will stay in the data entry mode. If a new value is not entered,
it will time out and the unit will continue to use its previous setting.
CODE 66 - “OPERATOR ACCESSIBLE FUNCTIONS” MODES
The Gemini 3300 has six basic levels of “Operator Accessible Functions”.
Each of these levels can be modified to enable or disable manual reset. When
the “PGM. DIS.” (Program Disable) terminal is connected to “COMMON”,
access to all functions is disabled except for those listed below which will
remain enabled. All of the function codes and parameters can be interrogated,
regardless of the “Operator Accessible Functions” mode selected.
A “-” sign in front of the mode identifier will disable the front panel Reset
button and the “RST.” terminal.
Note: The front panel reset button can be independently disabled by using the
disable reset DIP switch.
[66 1] NO FUNCTIONS ENABLED EXCEPT RESET - In this mode, manual
reset is enabled, but none of the programming functions can be changed.
[66 2] PRESET PROGRAMMING AND RESET ENABLED - In this mode,
manual reset and the programming of the Preset Values are enabled.
[66 3] SCALE FACTOR PROGRAMMING AND RESET ENABLED - In
this mode, manual reset and the programming of the Scale Factor Value
are enabled.
[66 4] SCALE FACTOR, PRESET PROGRAMMING AND RESET
ENABLED - In this mode, manual reset and the programming of the Scale
Factor and Preset Values are enabled.
[66 5] PRESET, COUNTER LOAD PROGRAMMING, 2-BUTTON RESET
AND RESET ENABLED - In this mode, manual reset and the programming
of the Presets, Counter Load Values and 2-Button Reset are enabled.
[66 6] PRESET, SCALE FACTOR, COUNTER LOAD PROGRAMMING,
2-BUTTON RESET AND RESET ENABLED - In this mode, manual reset
and the programming of the Presets, Scale Factor, Counter Load Values
and 2-Button Reset are enabled.
[66 -1]
[66 -2]
[66 -3] These modes are the same as above with the exception
[66 -4] that manual reset (Reset Button & Terminal) is disabled.
[66 -5]
[66 -6]
