[52 1] TERMINATE AT OUTPUT 2 START - Output 1 (O1) will terminate
when Output 2 starts. Output 1 is set for normal phase operation.
[52 2] TERMINATE AT OUTPUT 2 END - Output 1 (O1) will terminate
when Output 2 ends. Output 1 is set for normal phase operation.
[52 3] TERMINATE AT MANUAL RESET - Output 1 (O1) activates when
the Process Counter Value reaches the Preset 1 value. In this mode, once
Output 1 is activated, it does not deactivate until the moment a manual reset
occurs. Output 1 is set for normal phase operation.
[52 4] TERMINATE AT MANUAL RESET END - This mode is like the
preceding, except Output 1 (O1) deactivates when manual reset ends.
Output 1 is set for normal phase operation.
[52 5] TERMINATE AFTER TIMED OUTPUT 1 - Once Output 1 (O1) has
been activated, it will deactivate after the predetermined length of time
(Code 53) has expired. Manual reset will override the timed output and
reset Output 1. Output 1 is set for normal phase operation.
[52 -1]
[52 -2]
[52 -3] These modes are the same as above with the exception
[52 -4] that the output is set for reverse phase operation.
[52 -5]
CODE 53 - TIMED OUTPUT 1 VALUE
The Gemini 3300 has the capability of varying the Timed Output 1 Value
from 0.01 second to 599.99 seconds. When the code is entered, instead of a
single mode identifier digit being displayed, six digits will be shown. Refer to
“Programming the Presets, Scale Factor, Timed Outputs & Counter Load
values” section for more details about entering. The timed output will be
terminated if the Process counter is manually reset.
Note: A Timed Output value of zero cannot be programmed into the Gemini
3300. If a value of 0 is entered into the display and the “E” key is pressed,
the unit will not enter the 0, but will stay in the data entry mode. If a new
value is not entered, it will time out and the unit will continue to use its
previous setting.
CODE 54 - OUTPUT 2 TERMINATION MODES
The Gemini 3300 has five “Output 2 Termination Modes”, which control the
way Output 2 (O2) will terminate or reset. An Output 2 response will occur when
the Process Counter reaches the Preset 2 value or zero. In all modes, Output 2 will
terminate immediately when the Process Counter is manually reset.
A reverse phase mode is available on the Gemini 3300. This refers to the
complementing of the logic state of the output. With normal phase operation,
when the Process counter value reaches Preset 2, Output 2 will turn on. The
reset condition of Output 2 is output off. In reverse phase operation, Output 2
turns off when Preset 2 is reached. The reset condition of Output 2 is output
on. (Note: The state of the relay, if used, is also reversed.) A “-” sign in front
of the mode identifier will provide for reverse phase operation. The absence
of a “-” sign will indicate normal phase operation.
[54 1] TERMINATE AT OUTPUT 1 START - Output 2 (O2) will terminate
when Output 1 starts. Output 2 is set for normal phase operation.
[54 2] TERMINATE AT OUTPUT 1 END - Output 2 (O2) will terminate
when Output 1 ends. Output 2 is set for normal phase operation.
[54 3] TERMINATE AT MANUAL RESET - Output 2 (O2) activates when
the Process Counter reaches the Preset 2 value or zero. In this mode, once
Output 2 is activated, it does not deactivate until the moment a manual reset
occurs. Output 2 is set for normal phase operation.
[54 4] TERMINATE AT MANUAL RESET END - This mode is like the
preceding, except Output 2 (O2) deactivates when manual reset ends.
Output 2 is set for normal phase operation.
[54 5] TERMINATE AFTER TIMED OUTPUT 2 - Once Output 2 (O2) has
been activated, it will deactivate after the predetermined length of time
(Code 55) has expired. Manual reset will override the timed output and
reset Output 2. Output 2 is set for normal phase operation.
[54 -1]
[54 -2] These modes are the same as above with the exception
[54 -3] that the output is set for reverse phase operation.
[54 -4]
[54 -5]
