Install the stacker
1. Connect the cables between the stacker and the printer.
2. Switch on the stacker.
3.
Select the icon on the printer's front panel, then Accessories > Stacker > Install
stacker. The front panel will prompt you to attach the stacker to the printer.
4. There are two latches on the stacker that engage with the printer deflectors. To attach the stacker
to the printer, attach first one side and then the other (because less force is required that way).
NOTE: The stacker operates on cut sheets of paper. When it is switched on, the cutter is
automatically enabled. It cannot work if the cutter is turned off or if the printing material cannot be cut
(canvas, for example).
Uninstall the stacker
1.
To uninstall the stacker, select the icon on the printer's front panel, then Accessories >
Stacker > Uninstall stacker.
2. The front panel will then prompt you to detach the stacker from the printer. Pull the stacker from
one side to detach it on that side, then detach the other side.
3. Disconnect the stacker cables.
Using paper with the stacker
The stacker can handle cut sheets of paper between 420 mm (A3 portrait) (16.5 in) and 1189 mm (A0
portrait) (46.8 in) in length. Shorter prints will be enlarged to the minimum length with extra white
space; longer prints risk falling off the stacker.
Some printing materials are not compatible with the stacker, including:
● Matte and clear film
● Glossy paper (except instant-dry glossy paper, which may be used)
● Heavyweight coated paper
● Canvas
