Figure 1.1: Example System Configuration
Table 1.1: DSView 3 Software System Configuration Descriptions
Number
Description
Number
Description
1
DSView 3 Software Client
12
Power Device
2
Hub DSView 3 Software Server
13
Generic Appliance
3
Spoke DSView 3 Software Servers (Optional)
14
Hypervisor Manager
4
External Authentication Servers (Optional)
15
Target Device
5
SNMP Manager (Optional)
16
IQ Module
6
TCP/IP
17
Cascade Switch
7
Replication
18
Target Devices
8
ACS Advanced Console Server
19
MergePoint SP Manager
9
Power Device
20
Hypervisor Server
10
DSR Switch
21
Virtual Machines
11
OSCAR® Interface
22
Blade Chassis
