Auto/Manual Control: User-selectable as either 0% primary power
(Out Turnoff) or adjustable output power
(Manual Control) with “bumpless” transfer.
Cycle Times: Selectable from 1
2
s to 512 secs in binary
steps.
Setpoint Range: Limited by Setpoint Maximum and Setpoint
Minimum.
Setpoint Maximum: Limited by Setpoint and Range Maximum.
Setpoint Minimum: Limited by Range Minimum and Setpoint.
Setpoint Ramp: Ramp rate selectable 1 - 9999 LSDs per
hour and infinite. Number displayed is
decimal-point-aligned with selected
range.
A.8 SOFT START
Start-up Setpoint: Bounded by Range Maximum and Range
Minimum. Setpoint ramping is not applied
during Soft Start.
Duration: 0 (Soft Start disabled) - 59 mins 45 secs in
15-second increments.
Time remaining: Starts timing at instrument power-up in
1-second increments. Soft Start ends when
time remaining equals zero.
Power Maximum: Limits Output 1 power.
Soft Start enabled: only limits during Soft
Start.
Soft Start disabled: limits at all times.
Output 1 Cycle Time: Implicit. Cycle time used for Output 1
during Soft Start equals 1
4
displayed value
of Output 1 Cycle Time, but never less than
0.5 secs.
Operating Mode: Assumes reverse-acting control.
S075-A A-8
PM-0075
