A.5 OUTPUT 2
General
Types Available: Relay, Dual Relay (with Output 4), SSR Drive
and Solid State.
Relay
Contact Type: Single pole double throw (SPDT).
Rating: 2A resistive at 120/240V AC.
Lifetime: >500,000 operations at rated
voltage/current.
Isolation: Inherent.
SSR Drive/TTL
Drive Capability: SSR >4.5V DC into 250 Ω minimum.
Isolation: Not isolated from input or other SSR outputs.
Dual Relay (Output 2 and Output 4)
Contact Type: Single pole single throw - normally open.
Both relays share a single common
terminal.
Rating: 2A resistive at 120/240V AC
Lifetime: >500,000 at rated voltage/current.
Isolation: Inherent.
Solid State
Operating Voltage Range: 20 - 280Vrms (47 - 63Hz)
Current Rating: 0.01 - 1A (full cycle rms on-state @ 25 ° C);
derates linearly above 40 ° C to 0.5A @
80 ° C.
Max. Non-repetitive Surge
Current (16.6ms):
25A peak
Min. OFF-State dv
dt
@ Rated
Voltage:
500V/ µ s
