Thermo Fisher Scientific CyberScan 6000 Series Meters v.1 - Manual (Page 34)

22
Using the 6000 Series Meter: Button Functions
PH6000, PC6000, PH6500, CON6000, DO6000, PC6500 and PCD6500 meters
Technology Made Easy ...
The touch screen of your 6000 series bench meter has “buttons” along the right side of the
screen that are common to many of the screens. The following indicates the function of these
common buttons.
The Channel 1, Channel 2, Channel 3, Channel 4 and Channel 5 buttons access
the single display screen corresponding to each channel. If you wish to perform
standardization or printing from any of the channels, you need to use single channel
mode. The Graph can only be viewed in the single channel mode.
Channel 1 pH, mV or *(ion) channel Available in PH6000,PC6000, PH6500, PC6500
and PCD6500
Channel 2 pH, mV or *(ion) channel Available in PH6500, PC6500 and PCD6500
Channel 3 pH (FET) channel Available in PH6000,PC6000, PH6500, PC6500
and PCD6500
Channel 4 DO, BOD, OUR, SOUR channel Available in DO6000 and PCD6500
Channel 5 Conductivity, Resistivity, TDS or
Salinity channel
Available in PC6000, CON6000, PC6500 and
PCD6500
NOTE: *(ion) channel is for PH6500, PC6500 and PCD6500 meters only.
The Mode button allows you to switch between the various operations of the meter—pH, mV,
ion, pH (FET), DO, conductivity, resistivity, TDS and salinity. It also lets you configure the display
options, select input parameters, and view the software revision and serial number details.
The Setup button will access the setup screens of the channels that you are currently using.
The Log Data button sends data to the data storage center of the meter if sample ID # has been
assigned to your sample.
The Profile button lets you view your
profile (User ID, Password, Company
Name, User Group). You can change only
your profile and not of any other user.
You can change to a different user only
if you are the default user of the system.
The Home button accesses the Windows CE desktop. The 6000 series application does not
shut down if Home is pressed and the current user remains logged in. Double tap on the
6000
series icon to return to the previous screen before the Home button was pressed.
The Logoff button allows you to logoff the current user from the 6000 series application. The
6000
series application shuts down returning to the Win CE desktop. When you re-start the
application, you go to the main screen of the application. The second time you are logged in as
the default user of the system.
The Help button allows you to access helpful information on any screen. Touching the Help
button gives you information about the current screen. This information will include step-by-step
instructions for operating the meter from the current screen and possible applications information
for that screen.
