allow your flowmeter to be subjected to a simple and rapid diagnosis.
•
Press the following keys for a display of the status codes:
Key
Display
Description
→
Fct. 1.00
OPERATION
↑
Fct. 2.00
TEST
→
Fct. 2.01
TEST Q.
↑
Fct. 2.02
HARDW. INFO
If “YES” is selected in Fct. 3.04 ENTRY CODE,
key in 9-stroke CODE 1 now:
→
→
→
↵
↵
↵
↑
↑
↑
.
→
→
MODUL ADC
- . - - - - - . - -
1st window
- - - - - - - - -
↵
→
MODUL I/O
- . - - - - - . - -
2nd window
Example for status code:
- - - - - - - - -
3.25105.02 (8-character code, 1st line)
↵
→
MODUL DISP. - . - - - - - . - -
3rd window
3A47F01DB1 (10-character code, 2nd line)
- - - - - - - - -
↵
→
MODUL RS
- . - - - - - . - -
4th window
- - - - - - - - -
PLEASE NOTE DOWN ALL 8 STATUS CODES !
↵
Fct. 2.02
HARDW. INFO
Terminate hardware information
(2x) 3x
↵
- - - - - - - -
- - - - - / - - -
back to measuring mode
In “MODUL RS” , there are a few possible “error codes” that can possibly be solved by the customer. Therefore the 10-
character status code (2nd line) must be used:
10-character code:
9 8 7 6 5 4 3 2 1 0
“character 6”- value
Errors regarding partly filled situations
0
1
2
3
4 5
6
7
8
9
A B C D E F
Pipe less than 10 % filled (see note 1)
X
X
X
X
X
X
X
X
Error in IFS 4000 PF primary head (see note 2)
X X
X X
X X
X X
Parity error in communication between primary head and signal converter
(see note 3)
X X X X
X X X X
Timeout error in communication between primary head and signal converter
(see note 4)
X X X X X X X X
note 1: The level in the measuring tube is too low. Flow indication will be turned off (0 %). Please take precautions to ensure
that the level is increased above 10 percent to make flow measuring possible again
note 2: There are one or more errors in the primary head electronics. See sect. 7.6
note 3: Communication between the primary head (IFS 4000 PF) and the signal converter (IFC 110 PF) is not valid. Please
check that the data cable is connected according to sect. 1.5.6.
note 4: There is no communication between the primary head (IFS 4000 PF) and the signal converter (IFC 110 PF). The
displayed value is being calculated assuming a fully filled pipe. In most cases (pipeline not fully filled), the displayed value will
be too high. Check the connections of the communication cable, see also sect. 1.5.6.
Example: If in “modul RS” of the hardware info menu the 10-digits code is given as “0001272292” the “character 6”-value
is “1”. In the table you can then see that the pipe is less than 10% filled.
