7.30830.32.00 40
→ → LINE FREQ. = set power frequency customary in country where instrument is used, press → key
(Please note: only applies to instruments with DC power supply)
•
50 Hz
•
60 Hz
Select with
↑ and ↓ keys.
Press
↵ key to change to subfunction “FLOW DIR.”.
→ → FLOW DIR. = set flow direction, press → key
•
+ DIR. for identification of flow direction see “+” arrow on primary head;
•
- DIR. F/R mode: identification of “positive” flow direction
Select with
↑ and ↓ keys.
Press
↵ key to return to Fct. 3.02 FLOWMETER.
Zero check, see Fct. 3.03 and sect. 7.1.
Please refer to sect. 2.5.7 “Standard factory settings”.
5.14 User-defined units
Fct. 3.05 USER UNIT
Press
→ key
→ → TEXT VOL. = set text for user-defined flow unit, press → key
•
Liter max. 5 characters, factory setting = “Liter” or “US MGal”
characters which can be assigned to each place: A-Z, a-z, 0-9 or “-“ (=blank character).
Change flashing number (cursor) with keys
↑ and ↓. Use ← and → keys to shift cursor 1 place to left or right.
Flashing numbers can also be directly set with the 10-key keyboard.
Press
↵ key to change to subfunction “FACT. VOL.”.
→ → FACT. VOL. = set factor F
M
for volume, press
→ key
•
1.00000 E+3 factory setting “1000” / Factor F
M
= volume per 1 m
3
.
Setting range: 1.00000 E-9 to 9.99999 E+9 (=10
-9
to 10
+10
)
Change flashing number (cursor) with keys
↑ and ↓. Use ← and → keys to shift cursor 1 place to left or right.
Press
↵ key to change to subfunction “TEXT TIME”.
→ → TEXT TIME = set text for required time, press → key
•
hr max. 3 places, factory setting = “hr” or “day”
Characters which can be assigned to each place: A-Z, a-z, 0-9 or “-“ (=blank character).
Change flashing number (cursor) with keys
↑ and ↓. Use ← and → keys to shift cursor 1 place to left or right.
Flashing numbers can also be directly set with the 10-key keyboard.
Press
↵ key to change to subfunction “FACT. TIME”.
→ → FACT. TIME. = set factor F
T
for time, press
→ key
•
3.60000 E+3 factory setting “3600” / set factor F
T
in seconds.
Setting range: 1.00000 E-9 to 9.99999 E+9 (=10 -9 to 10 +10 )
Change flashing number (cursor) with keys
↑ and ↓. Use ← and → keys to shift cursor 1 place to left or right.
Press
↵ key to return to Fct. 3.05 USER UNIT
Flashing numbers (cursor) can also be directly set with the 10-key keyboard.
