7.30830.32.00 35
→ → I ERROR = set error value, press → key
•
22 mA fixed value
•
0.0 – I
0%
mA variable value, only variable when I
0%
≥
1 mA, see “RANGE I” above
Select with
↑ and ↓ keys.
Change flashing number (cursor) with keys
↑ and ↓. Use ← and → keys to shift cursor 1 place to the left or right.
Flashing numbers (cursor) can also be directly set with the 10-key keyboard.
Press
↵ key to return to Fct. 1.05 CUR. OUTP. I
Please refer to sect. 2.5.7 “Standard factory settings”
Refer to sect. 2.5.6 for connection diagrams and to sect. 5.16 for characteristics.
5.8 Pulse outputs P and A1
Pulse output P 2nd pulse output A1
To be used for … electronic totalizer electromechanical or electronic totalizer
Terminals P and P
⊥
A1 and A
⊥
F
max
at full-scale range Q
100%
10.000 pulses/s 50 pulses/s
F
min
at full-scale range Q
100%
10 pulses/hr 10 pulses/hr
Max. switching current 30 mA (AC or DC) 100 mA (AC or DC)
200 mA (DC polarized)
see sect. 6.3
Remark - “PULSOUTP.” must be selected in
Fct. 3.07 HARDWARE, subfunction
“Terminal A1”
Fct. 1.06 PULS P and/or Fct. 1.07 PULS2 A1
Press
→ key
Press
→ key
→ → FUNCT. P = select function for pulse output, press → key
•
OFF switched off, no function
•
+ DIR. measurement in one direction, refer to selection of main flow direction in
Fct. 3.02 FLOW METER, subfunction “FLOW DIR.”
•
- DIR. see + DIR.
•
2 DIR. 2 flow directions, F/R mode, forward/reverse
Select with
↑ and ↓ keys.
Press
↵ key to change to subfunction “SELECT P”.
Exception: when “OFF” is selected, return to Fct. 1.06 PULS P or Fct. 1.07 PULS2 A1.
→ → SELECT P = select pulse type, press → key
•
PULSE/VOL. pulses per unit volume, flow
•
PULSE/TIME pulses per unit time for 100 % flow
Select with
↑ and ↓ keys.
Press
↵ key to change to subfunction “PULSWIDTH”.
