KROHNE TIDALFLUX IFM 4110 PF EN - Manual (Page 27)

7.30830.32.00 27
→ •
OFF
•
ON
•
ALL ERROR
•
FATAL.ERROR
•
INVERS D1 (inverse mode of D1 and D2)
•
INVERS A1 (inverse mode of A1 or A2 possible only if A1 is operated
as status output, see Fct. 3.07 HARDWARE, “terminal A1”)
•
SIGN I, P or P2
(F/R mode)
•
OVERFL. I, P or P2
(overloading the outputs)
•
EMPTY PIPE
•
TRIP. POINT
Press
→ key to change to character
Selection:
•
+ DIR.
•
- DIR.
•
2 DIR.
Press
↵ key to change to numerical setting
Setting range: 000 – 150 PERCENT
•
AUTO.RNG. Setting range: 05 – 80 PERCENT (= lower to upper range ratio 1:20 to 1:1.25,
value must be higher than that of Fct. 1.03 L.F. CUTOFF).
Press
↵ key to change to numerical setting.
Press
↵ key to return to Fct. 1.06, 1.07, 1.08 or 1.09 .
1.11
1.12 CONTROL C1
CONTROL C2 Control inputs C1 and C2
•
OFF
•
EXT. RNG. (external range change)
Setting range: 05-80 PERCENT (= lower to upper range ratio 1:20 to 1:1.25, value
must be higher than that of Fct. 1.03 L.F. CUTOFF)
Press
↵ key to change to numerical setting.
•
OUTP. HOLD (hold output values)
•
OUTP. ZERO (set outputs to “min. values”)
•
TOTAL.RESET (reset the totalizer)
•
ERROR.RESET (delete error messages)
Press
↵ key to return to Fct. 1.11 or 1.12 CONTROL C1 or C2
Fct. Text Description and settings
2.0 TEST Test menu
2.01 TEST Q Test measuring range Q
Precautionary query
•
SURE NO Press
↵ key to return to Fct. 2.01 “TEST Q”.
•
SURE YES Press
↵ key, then use ↑ key to select value:
-110 / -100 / -50 / -10 / 0 / +10 / +50 / +100 / +110 PCT.
of set full scale range Q
100%
.
Displayed value is available at outputs I and P.
Press
↵ key to return to Fct. 2.01 “Test Q”.
2.02 HARDW. INFO Hardware information and error status
Before consulting factory, please note down all 8 codes.
→ MODUL ADC
X . X X X X X . X X
Y Y Y Y Y Y Y Y Y Y
Press
↵ key to transfer to “MODUL IO”.
→ MODUL IO
X . X X X X X . X X
Y Y Y Y Y Y Y Y Y Y
Press
↵ key to transfer to “MODUL DISP.”.
→ MODUL DISP.
X . X X X X X . X X
Y Y Y Y Y Y Y Y Y Y
Press
↵ key to transfer to “MODUL RS”.
→ MODUL RS
X . X X X X X . X X
Y Y Y Y Y Y Y Y Y Y
Press
↵ key to return to Fct. 2.02 “HARDW. INFO”.
2.03 HARDW. TEST Hardware test
Precautionary query
•
SURE NO Press
↵ key to return to Fct. 2.03 “HARDW. INFO”.
•
SURE YES Press
↵ key to start test, duration approx. 60 s.
If errors are found, the first one is displayed. Press
↓ key to display next error.
List of errors see Section 4.5.
Press
↵ key to return to Fct. 2.03 “HARDW. TEST”.
