3. Display Description and Operation Procedure 25
CLASS:
Set the cleanliness level of the cleanroom to be measured. After configuring
this setting, the appropriate particle size for the configured CLASS can be
selected.
SCHEDULE: You can load a MAP file. If you select the file, the MAP function will be
activated and the MAP will be displayed.
ROOM: Input the size of the room to be measured.
LOCATION: Input the number of measurement points.
CYCLES: Input the measurement cycles.
SAMPLE T.: Input the sampling time.
The numeric value shown next to the each entry field is the recommended value based on CLASS,
ROOM and AIR DIRECTION (in EXTENTION tab). Tap [SET] to use the recommended value.
In the EXTENTION tab, configure the following;
- ROOM STATUS
- AIR DIRECTION (only for Federal Standard)
- COMMENT
[AIR DIRECTION]
- Select unidirectional when wind direction is
constant.
- Select nonunidirectional when wind direction
is not constant.
[ROOM STATUS]
Select either as-built, as-rest or operational.
- Select as-built when the cleanroom is setting up.
- Select as-rest when the cleanroom function is off.
- Select operational when the cleanroom function is
on.
[COMMENT]
Tap the entry field to display a keypad. Enter
comment and tap [Enter].
Tap [APPLY] to save the new settings.
(Authentication required).
Tap [OK] to save the new settings and return to
MODE screen. (Authentication required).
Tap [CANCEL] to discard the changes and close the
window.
Check “AUTO SAVE” to store the data automatically.
Check “AUTO PRINT” to print the data automatically.
Check “START DELAY” to use a delay time prior to a
measurement.
