3. Display Description and Operation Procedure 10
(1) Data Display: Displays numeric value, chart and map.
(2) Measurement
Condition/
Environment Data:
Displays measurement mode, measurement setting and measurement
status/
Displays the current status when using option sensors.
(3) Status Display: Displays the status of power source, pump, LD error, over count.
(4) START: Starts measuring in the configured mode. This button becomes “STOP”
button after sampling starts. Tap “STOP” button to stop sampling.
MONITOR: Performs a measurement and displays a measurement value. This mode
does not save measurement results. The measurement display value is
updated every second.
Selects measurement mode. Select either “SINGLE”, “CONTINUOUS”,
“INTERVAL”, “STATS”, “STANDARD” or “REMOTE” mode. Configures
advanced settings in items such as INTERVAL, SAMPLE T. and CYCLES
can be set in each mode. In “PRESET” loads stored measurement setting
file.
FILE: Loads, prints and deletes stored measurement data.
MENU:
Configures chart settings, alarm settings and system settings.
Indicates if the instrument is powered by the AC power cord or a battery. If it’s
battery-powered, the remaining battery level is also shown.
Indicates a pump error status. If the pump is operating abnormally, this icon will be
shown.
Indicates an LD error status. If the LD is operating abnormally, this icon will be
shown.
Indicates if the measurement count per second exceeds the maximum measurable
concentration.
Indicates if an instrument Alarm error is occurring. Tap this icon to cancel the Alarm
sound.
/
Switches between Total display and Single display.
is displayed when Total display is selected. is displayed when Single
display is selected.
The range of indicated data is as follows:
The numeric value will be indicated in black when Total display is set and in gray
when Single display is set.
Channel Total Display Single Display
0.3um X ≧ 0.3um 0.3um ≦ X ＜ 0.5um
0.5um X ≧ 0.5um 0.5um ≦ X ＜1.0um
1.0um X ≧ 1.0um 1.0um ≦ X ＜3.0um
3.0um X ≧ 3.0um 3.0um ≦ X ＜5.0um
5.0um X ≧ 5.0um 5.0um ≦ X ＜10.0um
10.0um X ≧ 10.0um X ≧ 10.0um
* X: detected particle count
