Creating Monitor Screens with
AddObserver Builder
1
2
3
4
Index
2.32 Changing Monitor Screen Display Properties
Procedure
Changing the Monitor Screen Size
1.
Deselect all objects on the monitor screen.
2.
Choose
Edit > Properties or right-click and select Properties.
The monitor screen properties dialog box is displayed.
Main Window
Title
Color
Display position on the AddObserver Panel
Size
Sub Window
Title
Color
Select whether to show the window on AddObserver Panel
Size
Display position on the AddObserver Panel
3.
Enter values for the width and height to change the size of the screen.
4.
Click
OK.
Note
A screen of up to 1,600 wide and 1,200 high can be created.
