2-16 IM WX11-01E
10. Press the ENTER key on the keyboard to confirm the entered character string and
complete the label.
When the text size is set to Auto,
the text contracts or expands to match
the size of the label frame if the frame
is resized.
Edtng from the Propertes Dalog Box
1. Click the Edt icon in the OBJECT group of the EDIT page of the operation panel,
or click the Edt button in the object bar.
2. Select the label you wish to edit in the editing area.
3. Choose Edt > Propertes or right-click and select Properties.
The label properties dialog box is displayed.
Click here to apply the fill color.
To change the style of the text,
click the appropriate icons.
4. Move the cursor to the desired item and click to enter a new value.
5. Click OK.
Note
If a label overlaps with a meter, AddObserver Panel will display the label hidden beneath the
meter. Therefore you should not allow labels and meters to overlap.
2.6 Creatng Labels
