Edtng from the Propertes Dalog Box
1.
Click the Edt icon under Objects in the EDIT page of the operation panel, or click
the Edt button in the object bar.
2.
In the Edit area, select the numeric out object you wish to edit.
3.
Choose Edt > Propertes or right-click and select Properties.
The numeric out object’s properties dialog box opens.
Click here to change the output channel to
be registered. An Output Channel dialog box
opens. Select the channel.
Character string to display before the output value
Select this check box (light blue) to enable the
decimal point, minimum, maximum, and unit settings.
Set the lower and upper limits that can be sent.
When the value exceeds this range it cannot be
sent, but it can be displayed.
When OFF, outputs from the dialog box.
When ON, the edit box is displayed in the
objects area, and the edited values are output.
4.
Move the cursor to the item you wish to edit, then enter a setting.
5.
Click the OK button.
2.20 Creatng Numerc Out Wndows
